Ford's famous 2 piece lug nuts

frank s

Well-Known Member
Joined
Jul 30, 2018
Threads
5
Messages
943
Reaction score
736
Location
san diego CA
Website
www.fsheff.com
First Name
frank
Vehicle(s)
Stang '19 Magnetic, EcoBoost™, Vert, MagneRide® PP
Vehicle Showcase
2
[...]
To remove and install, I used an old school cross wrench and of course, a dab of anti seize on the new lugs. They're all "arm torqued" and checked after a short drive and again after a few hundred miles. All is well here.
Just a reminder: the torque specified in all applications I know of is to be applied to threaded fasteners that are CLEAN and DRY, ON ALL CONTACT SURFACES. A "dab of anti seize" (sic) must be compensated by lowering applied torque. No, I have no idea how much of a reduction is indicated by introducing common lubricants, et cetera, on those CLEAN and DRY surfaces.
Sponsored



WildHorse

N/A or GO HOME
Joined
Jun 28, 2017
Threads
216
Messages
8,463
Reaction score
6,534
Location
Home World: CLASSIFIED
First Name
ⓇⒾⒸⓀⓎ ⓈⓅⒶⓃⒾⓈⒽ
Vehicle(s)
'17 S550
Vehicle Showcase
1
No, I have no idea how much of a reduction is
According to several sources, including Engineering Box, "Dry bolt torque is approximately 30% higher". so any lube would be 70% of dry.


ORRadtech

Well-Known Member
Joined
Sep 12, 2019
Threads
21
Messages
2,490
Reaction score
2,188
Location
Atlanta, Georgia
First Name
Dave
Vehicle(s)
18 Mustang EcoBoost convertible, 14 Ford Fusion SE
I have had Fords since 1979 - 4 Mustangs, 2 Explorers, 2 Expeditions, Taurus, Edge, Escape, F-150, Ranger, Focus (Yes I like the Blue Oval). This is the FIRST time I have ever heard anyone complain about the lugs....EVER. So nope....never a problem, you are over thinking it and seem to be looking for issues.
Well, I've owned Fords since '72 and the last 2 I've had (12 Edge & 14 Fusion) and my daughters 13 Fiesta all have lugs that have had to be replaced because of the crappy design. The Edge now has solid lugs, much nicer now.
I'll probably replace the ones on my 18 EcoBoost convertible with solid because I don't trust them to last long with having to torque them to 150 lounds.
While I'm on the subject of torque, how in hell are we supposed to change a flat with that crappy factory jack handle? I just put a ratcheting 16" breaker bar with a 16" cheater with a good 21mm deep well socket in the wheel well, just in case.


boB

Well-Known Member
Joined
Dec 10, 2018
Threads
15
Messages
1,040
Reaction score
1,016
Location
FL
First Name
boB
Vehicle(s)
2019 GT PP1
150 lb*ft seems like a lot, when Tire Rack and others show 85-90 for 14 mm wheel studs. Ford has had this spec since 2015 so there must be a good reason. 2014 was 100 lb*ft for a 1/2" stud.


Grimmer

Well-Known Member
Joined
Mar 31, 2016
Threads
20
Messages
522
Reaction score
202
Location
Utah
Vehicle(s)
2016 GT Manual
According to several sources, including Engineering Box, "Dry bolt torque is approximately 30% higher". so any lube would be 70% of dry.
If the dry torque is 130% of the wet torque (x), and the dry torque is specified at 150 ft-lbs, then: 1.30x = 150 ft-lbs. Solving for the wet torque (x), we get 150/1.30 = 115 ft-lbs.


Sponsored

BmacIL

Enginerd
Joined
Sep 21, 2014
Threads
69
Messages
15,010
Reaction score
8,920
Location
Naperville, IL
Vehicle(s)
2015 Guard GT Base, M/T
Vehicle Showcase
1
150 lb*ft seems like a lot, when Tire Rack and others show 85-90 for 14 mm wheel studs. Ford has had this spec since 2015 so there must be a good reason. 2014 was 100 lb*ft for a 1/2" stud.
85-90 is outside the normal range for typical M14 fastener torque specification. 150 falls within it, albeit on the higher end.

People always forget that the torque is specified to create elastic bolt stretch, which is what keeps the wheel retained under all conditions. It's not about the nut or the wheel.


boB

Well-Known Member
Joined
Dec 10, 2018
Threads
15
Messages
1,040
Reaction score
1,016
Location
FL
First Name
boB
Vehicle(s)
2019 GT PP1
85-90 is outside the normal range for typical M14 fastener torque specification. 150 falls within it, albeit on the higher end.

People always forget that the torque is specified to create elastic bolt stretch, which is what keeps the wheel retained under all conditions. It's not about the nut or the wheel.
I was going by the Caterpillar bolt tightening specs (yep, I have visited Aurora) since I still have the handbook. You are correct (and as you noted, most people forget) that the *only* thing that keeps a joint tight is bolt stretch.


Sivi70980

Well-Known Member
Joined
Feb 28, 2019
Threads
17
Messages
2,501
Reaction score
4,179
Location
Lacey, Washington
First Name
Mark
Vehicle(s)
2019 Ruby Red GT PP1 M6
I just arm tightened them, haven't lost a wheel yet. I check them when I check the oil.


BmacIL

Enginerd
Joined
Sep 21, 2014
Threads
69
Messages
15,010
Reaction score
8,920
Location
Naperville, IL
Vehicle(s)
2015 Guard GT Base, M/T
Vehicle Showcase
1

Sivi70980

Well-Known Member
Joined
Feb 28, 2019
Threads
17
Messages
2,501
Reaction score
4,179
Location
Lacey, Washington
First Name
Mark
Vehicle(s)
2019 Ruby Red GT PP1 M6
Hahah!! They're just lug nuts, nothing really scientific about them, they're tight enough to keep the wheels on or they aren't. I save my torque wrenches for the things that matter. I'm also not the guy to tighten the lugs in a circular pattern, star all the way. And because internet I'll say I'm not implying you are that guy/gal/person/dragon/cat/anything else you may decide to identify as. Happy Friday!!


Sponsored

BmacIL

Enginerd
Joined
Sep 21, 2014
Threads
69
Messages
15,010
Reaction score
8,920
Location
Naperville, IL
Vehicle(s)
2015 Guard GT Base, M/T
Vehicle Showcase
1
Hahah!! They're just lug nuts, nothing really scientific about them, they're tight enough to keep the wheels on or they aren't. I save my torque wrenches for the things that matter. I'm also not the guy to tighten the lugs in a circular pattern, star all the way. And because internet I'll say I'm not implying you are that guy/gal/person/dragon/cat/anything else you may decide to identify as. Happy Friday!!
You just proved you don't know what you're talking about, or anything about joint design.


Sivi70980

Well-Known Member
Joined
Feb 28, 2019
Threads
17
Messages
2,501
Reaction score
4,179
Location
Lacey, Washington
First Name
Mark
Vehicle(s)
2019 Ruby Red GT PP1 M6
You just proved you don't know what you're talking about, or anything about joint design.
Nope, just a warehouse/parts order guy. Never said I did know anything about joint design but I do know as I've said before that lugs are either tight enough or they aren't. In my 20 years (likely less than most on here) of driving and occasionally fixing a flat or changing to winter wheels, I've never had a single issue with a wheel or even lug nut coming off. I can be just as OCD about torqueing stuff down as the next guy but I'm saying lugs aren't that serious. I highly doubt a 5lbs. torque difference on a lug will lose you the race or a wheel on your way home from work. You never see a nascar pit crew out there torqueing their wheels specifically and you wont ever be able to tell me their impacts are so advanced they torque that specifically either. So I agree, I don't know the specifics of what you're talking about but this thread wasn't pertaining to all of that either soooo...


kent0464

Well-Known Member
Joined
Aug 31, 2019
Threads
12
Messages
399
Reaction score
213
Location
Virginia
First Name
Kent
Vehicle(s)
1983 Ford Ranger, 1986 SVO Mustang, 2017 Mustang GT PP, 2017 F150 3.5 Eco
Vehicle Showcase
1
If the dry torque is 130% of the wet torque (x), and the dry torque is specified at 150 ft-lbs, then: 1.30x = 150 ft-lbs. Solving for the wet torque (x), we get 150/1.30 = 115 ft-lbs.
Not really, a whole lot of tech and research goes into torque and lubes, that’s one of the reasons guys building engines etc get into trouble using motor oil for torque lube rather than the specified lube for the application.

OP
OP

Dadillac

Well-Known Member
Joined
Sep 7, 2019
Threads
34
Messages
293
Reaction score
172
Location
Iselin NJ
First Name
Don
Vehicle(s)
2018 Ecoboost Premium manual
Bought a set of Gorilla's last night. I have read too many horror stories about these lug nuts and do not want to chance anything. Murphy's Law and whatnot

Don


Norm Peterson

corner barstool sitter
Joined
Jul 22, 2013
Threads
11
Messages
9,011
Reaction score
4,720
Location
On a corner barstool not too far from I-95
First Name
Norm
Vehicle(s)
'08 GT #85, '19 WRX
I'm still on the factory tires and dred the day that a shop has to mount new tires and destroy my rims in the process. I'm leaning more and more towards mounting them myself, but would still need to find a shop to computer balance them.
Bring the wheels with the old tires still on them and the new tires to the shop of your choice after taking them off your Mustang. It may take a couple of trips each way, but the peace of mind may be worth it and the shop shouldn't mind not having to dismount and remount them to the car.


Norm
