2019+ Voodoo Changes

Discussion in 'Shelby GT350 Mustang' started by GrabberBlue, Jun 27, 2019.

  1. bauern

    bauern Well-Known Member

    First Name:
    Robert
    Vehicle(s):
    Ram 2500
    Joined:
    Aug 25, 2018
    Location:
    somewhere else
    Posts:
    148
    Likes Received:
    96
    0   0   0
    #91 bauern, Jul 12, 2019
    Last edited: Jul 13, 2019
    Can't think of one.

    I'll just add, as I know you are aware of it, the Coyote crank has .012" shorter stroke (edited to correct difference) and the Voodoo piston has a shorter deck height (.007"). You could use the block savings to get the 5.2 CP crank. You might even be able to buy the 2020 GT500 crank when the parts catalog gets updated.

    On a side note, I have had the 12:1 Voodoo pistons and the 12:1 Gen 3 pistons from J&E, both 3.700 bore, in front of me. The dome heights are different. You'll want to check if you use Voodoo pistons with Gen3 Coyote heads.

    Strokerswild and olaosunt like this.
  2. olaosunt

    olaosunt Well-Known Member

    Vehicle(s):
    Guard,base,M6,KB-2.DIB,auto,Hellion TT,2016 GT 350
    Joined:
    Jan 10, 2015
    Location:
    Indiana
    Posts:
    2,997
    Likes Received:
    805
    Rating:
    100%
    1   0   0
    Thanks for the information . I knew there werw minor” differences between the coyote crank and the 5.2 crank sold by Ford performance(it’s a lot more $$$ too) but did not know the details .

    I am “ technical challenged “ so I rely on on my engine builder (and experts like you willing to educate me) Lol

    My builder did already build me a 5.2 CP short block (coyote crank ) with the Gen 2 Voodoo block that replaced the MMR 5.2 that was in my 2015 Hellion car after the crank broke .

    If the voodoo pistons are different than the ones used on the Gen 3 coyote then Probably best to keep to my original plan to build a spare for my GT 350.

    Not in a rush(since CP build is planned as a spare for the 18 GT -hope I did not jinx myself ) so I may wait to see if they offer the predator short block or the crank but based on the price of the current 5.2 crank they sell it wont be cheap !

  3. bauern

    bauern Well-Known Member

    First Name:
    Robert
    Vehicle(s):
    Ram 2500
    Joined:
    Aug 25, 2018
    Location:
    somewhere else
    Posts:
    148
    Likes Received:
    96
    0   0   0
    I only brought up the Predator crank as in the past the OEM parts were cheaper than the same part from FR. For example, the Voodoo block from a dealer was a few hundred dollars cheaper than from FR. The dealer block didn't come with oil squirter, the timing chain dowels or a couple of oil galley plugs but they were easy and cheap to get. With the rise in prices from FR parts, just something to keep in mind.

    olaosunt likes this.
  4. olaosunt

    olaosunt Well-Known Member

    Vehicle(s):
    Guard,base,M6,KB-2.DIB,auto,Hellion TT,2016 GT 350
    Joined:
    Jan 10, 2015
    Location:
    Indiana
    Posts:
    2,997
    Likes Received:
    805
    Rating:
    100%
    1   0   0
    Hi Boss
    Thanks for being such a fountain of Knowledge and being always willing to share with us “technically challenged “ individuals like myself .

    I wanted the see what you would recommend for my Voodoo rebuild after bending a rod .
    I was running moderate amounts of boost with the 2.9 whipple and builder thinks I may have lifted the heads but not a 100% on the cause .

    Block is already sleeved and we will be using diamond pistons .
    I am debating where to upgrade to the ultralight weight Callies rods or stick to the Manley H rods as I had planned .
    I have seen 2 builds including honey badger use the Callie rods but there applications are different since the they are NA and road race .

    It will only cost $800 and a week delay to upgrade to the ultralight rods .
    Also the H rods are only rated to 700 ft-lbs but my engine builder says they are good to 1100 .

    Any thoughts?
    Thanks for any recommendations you have .

  5. Droopy1592

    Droopy1592 Well-Known Member

    First Name:
    Damien
    Vehicle(s):
    2017 GT350
    Joined:
    Apr 11, 2019
    Location:
    Atlanta
    Posts:
    370
    Likes Received:
    156
    0   0   0
    Are people that are getting replacement motors for pre-19 cars getting these updated parts as well, not just the block?

  6. Greg35

    Greg35 Well-Known Member

    First Name:
    Greg
    Vehicle(s):
    ' 18 GT350
    Joined:
    Feb 24, 2017
    Location:
    Oklahoma
    Posts:
    218
    Likes Received:
    105
    0   0   0
    Yes, read 1st pg. this thread. From all posts I've seen here and on GT350 Owners forum all replacement engines are in fact '19 GT350 R , "KA" engines ..

  7. Droopy1592

    Droopy1592 Well-Known Member

    First Name:
    Damien
    Vehicle(s):
    2017 GT350
    Joined:
    Apr 11, 2019
    Location:
    Atlanta
    Posts:
    370
    Likes Received:
    156
    0   0   0
    This is a first to me so probably have to explain it like I’m five... most people that report a replacement engine say they get a new block so not sure what’s being reused and what comes with the block...

  8. Greg35

    Greg35 Well-Known Member

    First Name:
    Greg
    Vehicle(s):
    ' 18 GT350
    Joined:
    Feb 24, 2017
    Location:
    Oklahoma
    Posts:
    218
    Likes Received:
    105
    0   0   0
    GrabberBlue...

  9. Shift

    Shift Well-Known Member

    Vehicle(s):
    a Ford
    Joined:
    Oct 28, 2015
    Location:
    CA
    Posts:
    2,500
    Likes Received:
    1,133
    0   0   0
    Even the intake manifold gets replaced, if that gives you any indication of how much is being replaced along with the entire engine itself.

  10. OP
    OP
    GrabberBlue

    GrabberBlue Well-Known Member

    First Name:
    Alex
    Vehicle(s):
    2017 Grabber Blue GT350
    Joined:
    Mar 23, 2015
    Location:
    Phoenix
    Posts:
    399
    Likes Received:
    190
    0   0   0
    All replacement engines are now the 2019 Long Blocks straight off the Niche Romeo Line. Got 650 miles on mine so far and she is doing great! Zero oil consumption.

    nodonut likes this.
  11. nodonut

    nodonut Well-Known Member

    First Name:
    Jesse
    Vehicle(s):
    1966 A code Fastback GT (wish I still had it), 2014 Explorer Sport, 2013 FLHTK Harley, 2019 GT350.
    Joined:
    Dec 23, 2018
    Location:
    Sacramento, CA
    Posts:
    98
    Likes Received:
    78
    0   0   0
    I picked mine up on July 5. Drove her back from Arizona to California. I just rolled over 2100 miles. ZERO oil consumption. I was going to change the oil at 1500 miles and was told by a Ford tech who works on GT350's that I should leave the break in oil and not change the oil until I roll over 3000/3500 miles. I was told some who have changed the oil at 1000 or 1500 miles, like I was going to, end up with the ticking sound because the valves didn't have time to seat properly with the break in oil. I can't help but think there may be something to that, because I kept the revs down below 3000 rpm for the 1st 100 miles and varied my speed and rpm's, with no high revs until I hit 1000 miles. She runs like a top now and hitting 7500 rpm in 3rd gear is definitely a sweet spot when jumping on the freeway. No oil consumption as of yet and no ticking sounds. Just FYI. fullsizeoutput_6257.jpeg

  12. Bulldogs22

    Bulldogs22 Well-Known Member

    Vehicle(s):
    2019 Shelby GT350
    Joined:
    Jan 17, 2019
    Location:
    Atlanta
    Posts:
    190
    Likes Received:
    128
    0   0   0
    I didn't go above 3000 for the first 100 miles but after that Ive hit up to 8000 now with 700 miles. I believe these race engines need to not be babied until a 1000 or so so I have been accelerating hard to about 7000 then letting it come down to about 3500 to build tons of pressure. Would like insight on the oil change at 1000 though because that's when I planned to do it to get all of the break in metal out.

    nodonut likes this.
  13. orangegrower

    orangegrower Well-Known Member

    First Name:
    Mike
    Vehicle(s):
    2019 GT350 - 2019 Aston Martin Vantage - 2019 Ranger Lariat
    Joined:
    Oct 19, 2017
    Location:
    Cave Creek, AZ
    Posts:
    335
    Likes Received:
    219
    0   0   0
    #103 orangegrower, Jul 23, 2019
    Last edited: Jul 23, 2019
    I have followed a lot of the 5.0 guys with the Coyote's and the typewriter tick noise. It seems like a lot (but not all) have run into the noise problems after early first oil changes. I have always done my first oil change early for obvious reasons. Maybe there is something to this. I also thought that factory breakin oil was a thing of the past but maybe not. I also thought I saw somewhere where someone sent in a sample of their factory oil to a lab and it came back as regular Motorcraft oil. Lots of questions to be answered by someone smarter than me.

    nodonut likes this.
  14. Bcobb85

    Bcobb85 Well-Known Member

    Vehicle(s):
    GT350
    Joined:
    Jul 28, 2016
    Location:
    Houston, Texas
    Posts:
    212
    Likes Received:
    124
    0   0   0
    Changed my oil at 500 miles, then again at 1,000 miles to get all of the debris from the build out. There is no break-in oil in our cars when they hit the dealers, only the standard Motocraft 5w-50.

    ...Just hit 18k miles on my motor, no issues.

  15. nodonut

    nodonut Well-Known Member

    First Name:
    Jesse
    Vehicle(s):
    1966 A code Fastback GT (wish I still had it), 2014 Explorer Sport, 2013 FLHTK Harley, 2019 GT350.
    Joined:
    Dec 23, 2018
    Location:
    Sacramento, CA
    Posts:
    98
    Likes Received:
    78
    0   0   0
    I am not an engineer and by no means am I an expert on any matter concerning cars. I simply know just enough to be dangerous!. I rely on input and advice from experts and experienced drivers such as the one's found in this forum. I cannot vouch for the Ford tech, but, I was told they do ADD a break in additive to the oil at the factory. I suppose the only way to find out for sure, would be to talk to those at Flat Rock or possibly at Ford Performance.
