Is that hat covering a man bun…?
There's not enough hair up there for anything, let alone a man bun. Funny how it'll grow on my face and not up top.
Sponsored


Last edited:

illtal

Well-Known Member
Joined
Nov 16, 2018
Threads
17
Messages
1,865
Reaction score
908
Location
USA
Vehicle(s)
2018 Mustang GT
I've been quoted, by more than one reputable builder, that a sleeved Predator (no supports) will accommodate well north of 2000hp. Hell, there's a guy here in AZ that is making 2000 on a non sleeved Predator
I think stock pistons are the problem when going for High HP. I think even the predators are cast hypereutetic like the standard Coyote. Those seem to be good to ~1300 @ the 9.5:1 Compression.

I think once you remove that limitation then it's up to tuning and boost to get you to the the number you want.


Sponsored

myfast70

Well-Known Member
Joined
Aug 14, 2016
Threads
3
Messages
162
Reaction score
116
Location
Az
Vehicle(s)
Mustang
I think stock pistons are the problem when going for High HP. I think even the predators are cast hypereutetic like the standard Coyote. Those seem to be good to ~1300 @ the 9.5:1 Compression.

I think once you remove that limitation then it's up to tuning and boost to get you to the the number you want.
Definitely wouldn't use a stock piston for the kind of power that I'm looking to make, forged or cast...


engineermike

Well-Known Member
Joined
Jul 15, 2018
Threads
16
Messages
4,119
Reaction score
3,483
Location
La
Vehicle(s)
2018 GTPP A10
Are they hypereutectic? I'll have a hard time seeing them using a low silicon forged piston from the factory.l
I don't know if they are hypereutectic, but the grafal coating makes hypereutectic almost unnecessary. Not sure if the Ford engineers see it that way....


illtal

Well-Known Member
Joined
Nov 16, 2018
Threads
17
Messages
1,865
Reaction score
908
Location
USA
Vehicle(s)
2018 Mustang GT
I don't know if they are hypereutectic, but the grafal coating makes hypereutectic almost unnecessary. Not sure if the Ford engineers see it that way....
What was the Piston to wall clearance?


Sponsored

engineermike

Well-Known Member
Joined
Jul 15, 2018
Threads
16
Messages
4,119
Reaction score
3,483
Location
La
Vehicle(s)
2018 GTPP A10
What was the Piston to wall clearance?
Obscene...if you're familiar with old-school thinking.

The coyote factory spec is actually 0.0002 interference to about .001 clearance. The Predator spec is about .001-.002. I just measured a production block and used pistons and they came out to .001 clearance on the nose.


illtal

Well-Known Member
Joined
Nov 16, 2018
Threads
17
Messages
1,865
Reaction score
908
Location
USA
Vehicle(s)
2018 Mustang GT
Obscene...if you're familiar with old-school thinking.

The coyote factory spec is actually 0.0002 interference to about .001 clearance. The Predator spec is about .001-.002. I just measured a production block and used pistons and they came out to .001 clearance on the nose.
Wow.....


K4fxd

Well-Known Member
Joined
Apr 2, 2020
Threads
102
Messages
10,365
Reaction score
8,501
Location
NKY
First Name
Dan
Vehicle(s)
2017 gt, 2002 FXDWG, 2008 C6,
The coyote factory spec is actually 0.0002 interference to about .001 clearance. The Predator spec is about .001-.002. I just measured a production block and used pistons and they came out to .001 clearance on the nose.
Is that due to the coating or is the piston that large?


illtal

Well-Known Member
Joined
Nov 16, 2018
Threads
17
Messages
1,865
Reaction score
908
Location
USA
Vehicle(s)
2018 Mustang GT
Obscene...if you're familiar with old-school thinking.

The coyote factory spec is actually 0.0002 interference to about .001 clearance. The Predator spec is about .001-.002. I just measured a production block and used pistons and they came out to .001 clearance on the nose.
I mean that will certainly keep the noise down, pretty sure they are 4032. That's literally almost no expansion.

Did that used block get nuked or is it still in good condition?


Cory S

Well-Known Member
Joined
Dec 10, 2019
Threads
47
Messages
3,355
Reaction score
3,697
Location
Bradford, NH
First Name
Cory
Vehicle(s)
2016 Mustang GT Premium
I mean that will certainly keep the noise down, pretty sure they are 4032. That's literally almost no expansion.

Did that used block get nuked or is it still in good condition?
Guaranteed they aren't 2618 yep.
