But I heard anything above 70% is good for e85r?
Just watch the STFT on the Ngauge/SCT. It'll tell yah right away. If it's trimming > 5%, it's too lean for the R tune.





Advertisement



K4fxd

Well-Known Member
Joined
Apr 2, 2020
Messages
2,425
Reaction score
1,219
Location
NKY
First Name
Dan
Vehicle(s)
2017 gt, 2002 FXDWG, 2008 C6,1965 Sunbeam Tiger (Stolen, Elk Heart Lake)
I've got a flex tune and the way I do it is drive 3 or 4 miles then do a KAM reset. Yes it is kind of a PIA but I have the peace of mind to know the car has learned the current tank's alcohol %

These cars really do need a return fuel system.


RoyalCrimsonGT

Well-Known Member
Joined
Mar 30, 2018
Messages
103
Reaction score
92
Location
San Diego, CA
First Name
Bong
Vehicle(s)
2018 MGT P, 10R80, PP1, MagneRide, ActiveExhaust
Vehicle Showcase
1
Just watch the STFT on the Ngauge/SCT. It'll tell yah right away. If it's trimming > 5%, it's too lean for the R tune.
Ok I’ll monitor that, thanks for the tip


RoyalCrimsonGT

Well-Known Member
Joined
Mar 30, 2018
Messages
103
Reaction score
92
Location
San Diego, CA
First Name
Bong
Vehicle(s)
2018 MGT P, 10R80, PP1, MagneRide, ActiveExhaust
Vehicle Showcase
1
I've got a flex tune and the way I do it is drive 3 or 4 miles then do a KAM reset. Yes it is kind of a PIA but I have the peace of mind to know the car has learned the current tank's alcohol %

These cars really do need a return fuel system.
KAM reset huh, maybe I’ll try that next time instead of disconnecting my battery


catchthecarp

Well-Known Member
Joined
Mar 13, 2017
Messages
430
Reaction score
196
Location
STL MO
Vehicle(s)
2017 White Platinum Premium GT
I asked Lund - they said don't drop below 80% on the E-85 tune. Think I might flash my Flex tune and check what the E% reads on the Ngauge, been awhile since I checked it.


K4fxd

Well-Known Member
Joined
Apr 2, 2020
Messages
2,425
Reaction score
1,219
Location
NKY
First Name
Dan
Vehicle(s)
2017 gt, 2002 FXDWG, 2008 C6,1965 Sunbeam Tiger (Stolen, Elk Heart Lake)
The nGuage inferrs A%. The only way to know is to measure.

On the tuning forums the spark is supposed to be the same from E60 to E85. I don't know this as fact, but is what is said.
If a tuner sets the borderline and MBT tables the same, I would run away.


BigBeed

Well-Known Member
Joined
Nov 11, 2015
Messages
167
Reaction score
68
Location
South Jersey
Website
www.instagram.com
First Name
Dave
Vehicle(s)
2019 GT Premium 401a PP2
A lot depends on the ethanol content of the e85 and your regular gas as well. Did my first fill up of e85 yesterday and loaded my flex tune before I left the house because I didn't want to do it in at the pump. My 93 octane read 12% and the e85 I got tested as 90%. After fill up when my car learned, it locked it as 82.4%. I had 7 miles to empty when I filled up.

I brought 2 5 gal VP jugs with me so I don't have to go back as often. The car is gonna be filled with 93 over the winter while she sleeps. In the spring I am going to fill up a barrel at the station and bring it home so I do not have to go as often as the closest station to me is about 40 mins away.


catchthecarp

Well-Known Member
Joined
Mar 13, 2017
Messages
430
Reaction score
196
Location
STL MO
Vehicle(s)
2017 White Platinum Premium GT
Flashed the Flex tune and checked the alch_pct - it's spot on. Not sure why my previous readings were always low compared to bottle tests, even after a KAM reset. I'm just happy it's now displaying a reasonable result.



catchthecarp

Well-Known Member
Joined
Mar 13, 2017
Messages
430
Reaction score
196
Location
STL MO
Vehicle(s)
2017 White Platinum Premium GT
The problem I have with the test bottle I bought from Amazon is that it can't easily be filled at the pump. I use a plastic baby bottle with a wide mouth and fill that at the pump and then transfer to the test bottle. It's a PITA.

OP

Wernerj18

Well-Known Member
Joined
Dec 2, 2019
Messages
63
Reaction score
12
Location
South Carolina
First Name
Josh
Vehicle(s)
2015 mustang gt
  • Thread starter
  • Thread Starter
  • #27
Flashed the Flex tune and checked the alch_pct - it's spot on. Not sure why my previous readings were always low compared to bottle tests, even after a KAM reset. I'm just happy it's now displaying a reasonable result.

I'm thinking mine may be a little low. Its reading about 77. I tested it to about 80-82.5. I did just flash my e85r tune. So excited to see how it goes!

What do you you guys use to monitor to ensure you aren't running lean? I'm watching stft. I think someone mentioned to not let it get above +5%


K4fxd

Well-Known Member
Joined
Apr 2, 2020
Messages
2,425
Reaction score
1,219
Location
NKY
First Name
Dan
Vehicle(s)
2017 gt, 2002 FXDWG, 2008 C6,1965 Sunbeam Tiger (Stolen, Elk Heart Lake)
I like the fact Lund didn't scale the AFR gauge.

85% corn and it reads 14.8 AFR

Make sure your long terms are 0 or close to that. STFT's will bounce around.

OP

Wernerj18

Well-Known Member
Joined
Dec 2, 2019
Messages
63
Reaction score
12
Location
South Carolina
First Name
Josh
Vehicle(s)
2015 mustang gt
  • Thread starter
  • Thread Starter
  • #29
I like the fact Lund didn't scale the AFR gauge.

85% corn and it reads 14.8 AFR

Make sure your long terms are 0 or close to that. STFT's will bounce around.
Yeah this annoyed me as well. Just watch it on ur dash if you want to check. Mine was showing about 9
