Active exhaust Harness failure

[nickhill]

Hey, my 2021 PP1 GT has the factory Active exhaust and I’m currently on my 3rd sliced harness on the passenger side. I’ve tried adjusting the exhaust to sit lower and the harness in different positions but am constantly plagued with the body cutting it. My next option is going to be notching the flap of pinch weld…any recommendations so I don’t have to cut up my car?

Sponsored



[NGOT8R]

Cut about 1” off of your exhaust pipes where they meet the x or h-pipe. This will allow you to slide the exhaust system forward to create enough clearance between the actuator harness and the pinch weld.



[SheepDog]

Hey, my 2021 PP1 GT has the factory Active exhaust and I’m currently on my 3rd sliced harness on the passenger side. I’ve tried adjusting the exhaust to sit lower and the harness in different positions but am constantly plagued with the body cutting it. My next option is going to be notching the flap of pinch weld…any recommendations so I don’t have to cut up my car?

The solution is not to lower the exhaust. The solution is to loosen the clamps at the resonator, and shove the entire exhaust forward as far as it will go.



[junits15]

The solution is not to lower the exhaust. The solution is to loosen the clamps at the resonator, and shove the entire exhaust forward as far as it will go.

This is the answer, you may have to cut some off of the exhaust as @NGOT8R said too.

I had to do this twice, its a bad design.



[John S]

It's a mass produced Mustang with sloppy build quality, I'm sure no one's feelings would be hurt by a BFH on the pinch weld.



[SheepDog]

There’s enough “slack” in the butt clamps between the resonator and the “S” pipes to push the exhaust all the way to the ends of the hangers. You will easily get 3” forward. No cutting or smashing required.
