I am considering tapping into my rear defroster circuit for a DIY differential cooler build.
This involves the interior, driveline, and is needed for the track. So I am posting in the General forum hoping for more views, haha.
My idea is
Operation is A) switch flipped to original defrost circuit during cold months, or B) switch flipped to diff cooler for warm months.
What I want help with is 1) circuit diagram, and 2) where/how the defrost wires run.
This involves the interior, driveline, and is needed for the track. So I am posting in the General forum hoping for more views, haha.
My idea is
- Leverage the rear defroster circuit, which comes from 40A Fuse# 9 in the engine bay.
- Cut into the hot line and install 2-way switch.
- Run second hot line to thermal switch and 7.5A fuse for the pump underneath.
Operation is A) switch flipped to original defrost circuit during cold months, or B) switch flipped to diff cooler for warm months.
What I want help with is 1) circuit diagram, and 2) where/how the defrost wires run.
