Return fuel system using stock basket?

cbrtrx

Well-Known Member
Joined
Nov 23, 2014
Threads
30
Messages
525
Reaction score
142
Location
tampa fl
Vehicle(s)
2016 mustang gt
Which companies offer kits that can reuse the factory basket? Id like to be able to run safely at 1/4 tank of fuel. So far I think it's just Radium and DW. Any others?


OP
OP
cbrtrx

cbrtrx

Well-Known Member
Joined
Nov 23, 2014
Threads
30
Messages
525
Reaction score
142
Location
tampa fl
Vehicle(s)
2016 mustang gt
Yes I'm just looking for something to handle a little bit more power, it seems hit or miss with that kit.


Jackson1320

Well-Known Member
Joined
Sep 26, 2019
Threads
25
Messages
3,007
Reaction score
1,178
Location
California
First Name
Jaxson
Vehicle(s)
2015 mustang gt
Yes I'm just looking for something to handle a little bit more power, it seems hit or miss with that kit.
Stock pump with a boost reference regulator larger lines bap rails=1000+
Stock pump bap 800+


illtal

Well-Known Member
Joined
Nov 16, 2018
Threads
14
Messages
1,187
Reaction score
389
Location
USA
Vehicle(s)
2018 Mustang GT
Stock pump with a boost reference regulator larger lines bap rails=1000+
Stock pump bap 800+

Those are gas numbers, probably not realistic on a 12:1 engine. Much lower on E-85 due to volume requirements. If you need to run E-85 you need a double pump situation. Either a GT350 pump solution or something of the sort.

What fuel are you running and what is your current setup op?



illtal

Well-Known Member
Joined
Nov 16, 2018
Threads
14
Messages
1,187
Reaction score
389
Location
USA
Vehicle(s)
2018 Mustang GT
Which companies offer kits that can reuse the factory basket? Id like to be able to run safely at 1/4 tank of fuel. So far I think it's just Radium and DW. Any others?
DW kit you can use it like stock since it is stick save for the hat and the extra pump.

OP
OP
cbrtrx

cbrtrx

Well-Known Member
Joined
Nov 23, 2014
Threads
30
Messages
525
Reaction score
142
Location
tampa fl
Vehicle(s)
2016 mustang gt
Stock pump with a boost reference regulator larger lines bap rails=1000+
Stock pump bap 800+
Yes I already found the limits are less then you posted for my application and E85.


Jackson1320

Well-Known Member
Joined
Sep 26, 2019
Threads
25
Messages
3,007
Reaction score
1,178
Location
California
First Name
Jaxson
Vehicle(s)
2015 mustang gt
Those are gas numbers, probably not realistic on a 12:1 engine. Much lower on E-85 due to volume requirements. If you need to run E-85 you need a double pump situation. Either a GT350 pump solution or something of the sort.

What fuel are you running and what is your current setup op?
If it can flow 600lph it don’t matter if it’s gas or e85 600lph is 600lph. More than needed for the 800 goal on e85 you set


Jackson1320

Well-Known Member
Joined
Sep 26, 2019
Threads
25
Messages
3,007
Reaction score
1,178
Location
California
First Name
Jaxson
Vehicle(s)
2015 mustang gt
Yes I already found the limits are less then you posted for my application and E85.
If you are running new lines boost reference regulator fuel rails and you took the fuel pump module out and removed the factory regulator then my numbers are accurate. You have to remove the factory regulator in the tank


Jackson1320

Well-Known Member
Joined
Sep 26, 2019
Threads
25
Messages
3,007
Reaction score
1,178
Location
California
First Name
Jaxson
Vehicle(s)
2015 mustang gt
Everyone just installs a pump booster. The stock regulator limits the capabilities of the stock pump. If the job is done right you removed the stock regulator in the tank as soon as you start upgrading the fuel system.


StickShiftyFifty

Well-Known Member
Joined
Nov 1, 2017
Threads
21
Messages
220
Reaction score
113
Location
CA
First Name
Steve
Vehicle(s)
2016 mustang pp
Rodeheaver using gt350 twin pumps, I think its good for 1200
