Front splitter/ tray drawing or part numbers

[icecreamtruckz]

Anyone have an assembly or exploded drawing of the GT350 front splitter and under tray assembly? Or list of part numbers including fasteners. Had mine on the lift recently and it’s pretty bad. Fasteners sheared off, damage to the lip in a few spots, it’s just got 40k miles worth of scrapes and I want to put a part list together.

Lots of trashed fasteners sheared off. Would like to refresh all of them while I have the old one off and all I can find is the part number for the plastic itself but not the hardware or even the size and dimensions of the hardware.

Sponsored



[Inthehighdesert]

Most dealer parts departments will email you the exploded view they have/use for the assemblys to figure out what you need. It’ll have all the part numbers on it as well. Some dealers are actually pretty close to the prices online with the shipping added in. Here’s an installation instruction that has some of the part numbers on it. It’s in the description pics. Also a link to a thread if you go down you’’ see the same instructions but has the parts list at the bottom.

https://blueovalindustries.com/prod...LerjSCN-x1d3iVtsWJtRqelrIwzBlg439ZeJYHSqjA129

https://www.svtperformance.com/threads/gt350-and-gt350r-splitter-fun.1132563/



[MAGS1]

@LevittownFordParts should be able to help as well



[MiamiGT350]

Enter your VIN on parts.ford.com and you should be able to see the Related Parts tab on this page.

https://parts.ford.com/shop/en/us/spoiler-panel-front-52l-(front-spoiler)-p-fr3z17626e?pdp=y



[LevittownFordParts]

See attached friends

- Benny
