Mustang cluster swap!

[Gremlin5.0]

HELP MY RPM IS NOT WORKING!!
I recently swapped the cluster in my 2016 base model pp1 mustang 6 speed for a 2019 premium pp1 cluster with my color features. I have used forscan to remove premium features from cluster but my RPM needle doesn’t work!! I have put the car in ET testing mode and the needle goes up just fine but doesn’t go up at all when car is idling. Any help plz!!!

Sponsored



[Pucklord]

Simple. Just put back your original cluster and using Forscan, save the stock IPC values. After that put the new cluster and using forscan write the IPC values that you saved and everything will works. P.S. Make sure to make a new profile on forscan after you put the new cluster



[Jays5ohh]

Are you taking about the ipc configuration file?



[Pucklord]

Yes
