Wider rims, need advice

OP
OP
TrackMustang

TrackMustang

Well-Known Member
Joined
Nov 24, 2021
Threads
22
Messages
676
Reaction score
778
Location
SoCal
Vehicle(s)
2021 Mustang GT
== CALIPERS ==
front
red: KR3Z-2B121-A, KR3Z-2B120-A <$263
orange: MR3Z-2B121-B, MR3Z-2B120-B <$332
https://www.tascaparts.com/oem-parts/ford-caliper-assembly-brake-less-pad-mr3z2b121b
https://www.bluespringsfordparts.com/oem-parts/ford-caliper-assembly-brake-less-pad-mr3z2b121b
https://parts.autonationfordwhitebe...rd-caliper-assembly-brake-less-pad-mr3z2b121b
rear
red: KR3Z-2552-A, KR3Z-2553-A $130
orange: MR3Z-2552-A, MR3Z-2553-A, $120
red bracket: KR3Z-2B511-A $114
I have 14” rotors, can I assume these require 15”??



NightmareMoon

Well-Known Member
Joined
Nov 22, 2015
Threads
35
Messages
4,242
Reaction score
2,797
Location
Austin
Vehicle(s)
2016 Mustang GT PP
Vehicle Showcase
1
Do you need spacers to switch from the 9.5 to the 11? If so what size? Do you have longer studs too, and presumably open lug nuts…? So many questions with four wheels…
You need camber to stuff the front 11" wheels under the fender - camber plates specifically because you need the room between the strut and fender which camber plates can give you.

Then, you need either
1) specific 11" wheels with ETs for the front (ET~26) - these will fit w/o spacers, but I only know two manufacturers who make front-specific 11" mustang offsets (without going full custom) - Apex is one and I forget the other.

OR 2) common 11" wheels ET~50-52 which fit the rear on our cars, a 25mm/1" slip on spacer, and extended studs which are at least 1" longer than stock - ARP makes some, and you can buy Ford hubs with these pre-installed, or just install them yourself.

OPMustang.com is a good source for studs and spacers, and the guy is very knowledgeable about and has been a great vendor to work with.

The advantage to 2 is you can freely rotate all four corners because they're all the same wheel offset and tire. With 1 you can't rotate front to rear (not everybody cares about that and you save some money not buying studs and spacers.


OP
OP
TrackMustang

TrackMustang

Well-Known Member
Joined
Nov 24, 2021
Threads
22
Messages
676
Reaction score
778
Location
SoCal
Vehicle(s)
2021 Mustang GT
You need camber to stuff the front 11" wheels under the fender - camber plates specifically because you need the room between the strut and fender which camber plates can give you.

Then, you need either
1) specific 11" wheels with ETs for the front (ET~26) - these will fit w/o spacers, but I only know two manufacturers who make front-specific 11" mustang offsets (without going full custom) - Apex is one and I forget the other.

OR 2) common 11" wheels ET~50-52 which fit the rear on our cars, a 25mm/1" slip on spacer, and extended studs which are at least 1" longer than stock - ARP makes some, and you can buy Ford hubs with these pre-installed, or just install them yourself.

OPMustang.com is a good source for studs and spacers, and the guy is very knowledgeable about and has been a great vendor to work with.

The advantage to 2 is you can freely rotate all four corners because they're all the same wheel offset and tire. With 1 you can't rotate front to rear (not everybody cares about that and you save some money not buying studs and spacers.

There is so much to this… motorcycles are so much more simple.


bnightstar

Well-Known Member
Joined
Mar 15, 2019
Threads
14
Messages
1,493
Reaction score
591
Location
Bulgaria
First Name
Hristofor
Vehicle(s)
2013 Ford Fiesta 1.25i, 2017 GB Ford Mustang GT PP Premium
Vehicle Showcase
1

bnightstar

Well-Known Member
Joined
Mar 15, 2019
Threads
14
Messages
1,493
Reaction score
591
Location
Bulgaria
First Name
Hristofor
Vehicle(s)
2013 Ford Fiesta 1.25i, 2017 GB Ford Mustang GT PP Premium
Vehicle Showcase
1

shogun32

Well-Known Member
Joined
Feb 8, 2019
Threads
78
Messages
11,286
Reaction score
7,825
Location
Northern VA
First Name
Matt
Vehicle(s)
2019 GT+PP, SS+1LE, 2020 F150
Vehicle Showcase
2

bnightstar

Well-Known Member
Joined
Mar 15, 2019
Threads
14
Messages
1,493
Reaction score
591
Location
Bulgaria
First Name
Hristofor
Vehicle(s)
2013 Ford Fiesta 1.25i, 2017 GB Ford Mustang GT PP Premium
Vehicle Showcase
1
OP
OP
TrackMustang

TrackMustang

Well-Known Member
Joined
Nov 24, 2021
Threads
22
Messages
676
Reaction score
778
Location
SoCal
Vehicle(s)
2021 Mustang GT
You should also look into the GT350 swap. Very easy and cheap (comparative with the PP/Bullitt kit) and has some inherent benefit over those in the caliper and pad design and also bigger rotors.
The ones I’ve seen are similar in price, unless I missed something?

OP
OP
TrackMustang

TrackMustang

Well-Known Member
Joined
Nov 24, 2021
Threads
22
Messages
676
Reaction score
778
Location
SoCal
Vehicle(s)
2021 Mustang GT
You need camber to stuff the front 11" wheels under the fender - camber plates specifically because you need the room between the strut and fender which camber plates can give you.

Then, you need either
1) specific 11" wheels with ETs for the front (ET~26) - these will fit w/o spacers, but I only know two manufacturers who make front-specific 11" mustang offsets (without going full custom) - Apex is one and I forget the other.

OR 2) common 11" wheels ET~50-52 which fit the rear on our cars, a 25mm/1" slip on spacer, and extended studs which are at least 1" longer than stock - ARP makes some, and you can buy Ford hubs with these pre-installed, or just install them yourself.

OPMustang.com is a good source for studs and spacers, and the guy is very knowledgeable about and has been a great vendor to work with.

The advantage to 2 is you can freely rotate all four corners because they're all the same wheel offset and tire. With 1 you can't rotate front to rear (not everybody cares about that and you save some money not buying studs and spacers.

what specifically is the advantage of 11s over 10s?This seems like more work than getting a 10 to fit, is it worth it? Why/how?

Last edited:

EFI

Well-Known Member
Joined
May 19, 2015
Threads
60
Messages
3,623
Reaction score
2,217
Location
Masshole central
Vehicle(s)
5.Br0
The ones I’ve seen are similar in price, unless I missed something?
You're probably looking at the whole "kit" from a vendor that are usually has more expensive.

Buying just the barebones from a dealer or Ford parts vendor is cheaper.

I bought the whole front end GT350 kit for under $1k. Could even be done for a few hundred less had I not chosen to do the studs and ss lines and re-used the existing hardware. I went with the studs for easier pad/rotor swap at the track, not something that's needed for a street car.

Front calipers
Front pads
Steel rotors
Conversion brackets with the optional studs
Stainless lines


EFI

Well-Known Member
Joined
May 19, 2015
Threads
60
Messages
3,623
Reaction score
2,217
Location
Masshole central
Vehicle(s)
5.Br0
what specifically is the advantage of 11s over 10s?This seems like more work than getting a 10 to fit, is it worth it? Why/how?
You get a wider tires, for a track car it's very beneficial to fit a 305-315 tire over a 275-285 especially on the front of a nose heavy car.


Vert

Well-Known Member
Joined
Apr 20, 2018
Threads
7
Messages
336
Reaction score
203
Location
Indiana
Vehicle(s)
Whipped 19 GT Premium
It all depends on what you want to spend, but for him I went with late model restoration wheels. Great budget buy with light weight rim.
