What did you do to your S550 Mustang today?!

Cheo

Well-Known Member
Joined
Mar 25, 2017
Threads
15
Messages
235
Reaction score
227
Location
Arizona
Vehicle(s)
Mustangs
Ford Performance toe link bearings and BMR vertical links. The bearings were a royal PITA, we’ll see how the rear end behaves next autox day.







2016S550

Well-Known Member
Joined
Feb 19, 2014
Threads
13
Messages
417
Reaction score
398
Location
USA
Vehicle(s)
Shopping
Ford Performance toe link bearings and BMR vertical links. The bearings were a royal PITA, we’ll see how the rear end behaves next autox day.





Good job. What tool did you use to remove the stock bushings?


DougS550

Well-Known Member
Joined
May 18, 2020
Threads
147
Messages
2,240
Reaction score
1,058
Location
Indiana
First Name
Doug
Vehicle(s)
2019 Ford Mustang GT Premium
Good job. What tool did you use to remove the stock bushings?
Kudos to you for having the tools to replace them for I know they were tight. For me, I didn't want to buy a bearing press so I had a local shop do mine. You did good.



2016S550

Well-Known Member
Joined
Feb 19, 2014
Threads
13
Messages
417
Reaction score
398
Location
USA
Vehicle(s)
Shopping
Kudos to you for having the tools to replace them for I know they were tight. For me, I didn't want to buy a bearing press so I had a local shop do mine. You did good.
I am trying to find anyone who has used the fulltiltboogieracing tool that is supposed to make this job much easier but cannot find anyone who has used it.


DougS550

Well-Known Member
Joined
May 18, 2020
Threads
147
Messages
2,240
Reaction score
1,058
Location
Indiana
First Name
Doug
Vehicle(s)
2019 Ford Mustang GT Premium
I am trying to find anyone who has used the fulltiltboogieracing tool that is supposed to make this job much easier but cannot find anyone who has used it.
Man I tried Auto Zone Tool rental, Harbor Freight, I even bought a bearing, bushing removing tool kit from azon. None of the had large enough adapter for me to do them. Post the tool that works and pass on for the next person. They are Tight.


DougS550

Well-Known Member
Joined
May 18, 2020
Threads
147
Messages
2,240
Reaction score
1,058
Location
Indiana
First Name
Doug
Vehicle(s)
2019 Ford Mustang GT Premium
I am trying to find anyone who has used the fulltiltboogieracing tool that is supposed to make this job much easier but cannot find anyone who has used it.
I stripped one of those trying. Use allot of anti size grease on the threads. I still stripped them. Post pics.


Cheo

Well-Known Member
Joined
Mar 25, 2017
Threads
15
Messages
235
Reaction score
227
Location
Arizona
Vehicle(s)
Mustangs
Good job. What tool did you use to remove the stock bushings?
This is all I used, my impact is rated to 700ft/lbs so that helped, don‘t use the 1 1/4 socket the instructions say to use, too small. 1 5/16 or 33mm impact socket with flat back works best (NAPA carries them). I used penetrating oil for an hour, cleaned everything up with brake cleaner, also had new bearings in freezer overnight. Remove and install from front to back of vehicle.

ball joint press https://www.eastwood.com/eastwood-4...kedid=555900045761&wickedsource=google&wv=3.1




DougS550

Well-Known Member
Joined
May 18, 2020
Threads
147
Messages
2,240
Reaction score
1,058
Location
Indiana
First Name
Doug
Vehicle(s)
2019 Ford Mustang GT Premium
Did you use the FTBR kit? I have not purchased anything as of yet.
No I used another kit. What I was missing was the correct OD diameter sleeves with the same OD as the bearing used to press the bearing out, and I couldn't find a sleeve which had a ID for the other side for the bearing to slide into as it is pressed out. Just find a kit with sleeves which have the correct OD and ID to press them out. I just got tired of messing with it and removed the LCA and took them to a shop which had a bearing press. Imine we're just to tight to do on car. Good luck


Gnatsum21

Well-Known Member
Joined
Oct 31, 2021
Threads
9
Messages
719
Reaction score
1,222
Location
Fort Lauderdale FL
Vehicle(s)
GT 2021

rcald

Well-Known Member
Joined
Jan 18, 2021
Threads
8
Messages
160
Reaction score
234
Location
Treasure Coast, Florida
First Name
Randy
Vehicle(s)
2020 Bullitt L3483 2015 Rover Discovery Sport HSE
Last edited:

nustang

Well-Known Member
Joined
Nov 17, 2020
Threads
4
Messages
318
Reaction score
432
Location
BC, Canada
Vehicle(s)
2020 GT, performance pak, active exhaust


That tool looks like a piece of 1/2" ready rod.
Its total garbage if it is.

I made something almost identical using ready rod.
Bushing didnt budge, and the ready rod threads stripped/stretched rendering it useless.
Got a puller with a tool steel threaded rod and nut. That worked, but still a lot of torque to break the bushing free. Also had a ball bearing as a thrust washer on the driving end.
You'll need every advantage
