MMR cooling head head mod

JCSIX13

Well-Known Member
Joined
Jun 6, 2016
Messages
329
Reaction score
69
Location
MA
First Name
Jack
Vehicle(s)
2016 GT350
Vehicle Showcase
1
Is there a installation write up or video on this with the motor and transmission still in the car? How can you get access to the freeze plugs to get them out?

Thanks
Jack
Advertisement



slime_bullet

Well-Known Member
Joined
Oct 29, 2019
Messages
50
Reaction score
18
Location
Louisiana
First Name
Brett
Vehicle(s)
2015 Mustang GT
From what I've gathered, take the intake manifold off and use pliers


Jackson1320

Well-Known Member
Joined
Sep 26, 2019
Messages
2,281
Reaction score
795
Location
California
First Name
Jaxson
Vehicle(s)
2015 mustang gt
If you have never done it before then you will probably find removing the intake manifold very helpful. It’s really a easy install

OP
OP
JCSIX13

JCSIX13

Well-Known Member
Joined
Jun 6, 2016
Messages
329
Reaction score
69
Location
MA
First Name
Jack
Vehicle(s)
2016 GT350
Vehicle Showcase
1
I have and plan on removing the intake. Just know that there is not much room back there. I can't see how you can grab them with pliers. I have only seen it done with the engine out of the car and then using a screwdriver and a hammer. I know it can be done in the car just like to hear from someone that has done it.

Thanks
Jack


Jackson1320

Well-Known Member
Joined
Sep 26, 2019
Messages
2,281
Reaction score
795
Location
California
First Name
Jaxson
Vehicle(s)
2015 mustang gt
I use a small air cylinder to punch it in then grab it with long 90* needle nose


80FoxCoupe

Well-Known Member
Joined
Mar 28, 2018
Messages
3,142
Reaction score
2,621
Location
Cincy, OH
Vehicle(s)
16 GT, 80 Fox

Angrey

Well-Known Member
Joined
Jun 21, 2020
Messages
847
Reaction score
580
Location
Coral Gables
Vehicle(s)
2016 GT350
Install the MMR Cooling Mod in a 5.2 GT350 - YouTube

This is Honey Badger's vid.

I honestly don't see how it could be done with the motor in the car. First, even if you disconnect the trans and motor mounts, you can't really tip the motor the correct direction to provide proper clearance.

You might be able to get the OEM plug out, but inserting the new piece is going to be a royal pain in the ass without the ability to push or tap on the new one with a rubber mallet.

I used the freezer technique as well.


Sigman

Member
Joined
Feb 8, 2021
Messages
24
Reaction score
7
Location
TEXAS
First Name
Eric
Vehicle(s)
2020 GT Mustang MT82
Will likely need to unbolt and drop the K-member in order to gain access.


80FoxCoupe

Well-Known Member
Joined
Mar 28, 2018
Messages
3,142
Reaction score
2,621
Location
Cincy, OH
Vehicle(s)
16 GT, 80 Fox
Does this mod even do anything? I dont see it.


Whitedevil95

Well-Known Member
Joined
Apr 25, 2019
Messages
441
Reaction score
229
Location
Temecula, CA
First Name
J.P.
Vehicle(s)
2017 Mustang GT
Does this mod even do anything? I dont see it.
Good Question! I mean if ford had this flaw in C heads 20 years ago and still cant fix it then WOW.


80FoxCoupe

Well-Known Member
Joined
Mar 28, 2018
Messages
3,142
Reaction score
2,621
Location
Cincy, OH
Vehicle(s)
16 GT, 80 Fox
Good Question! I mean if ford had this flaw in C heads 20 years ago and still cant fix it then WOW.
So are you saying this mod is necessary or unnecessary?


Whitedevil95

Well-Known Member
Joined
Apr 25, 2019
Messages
441
Reaction score
229
Location
Temecula, CA
First Name
J.P.
Vehicle(s)
2017 Mustang GT
So are you saying this mod is necessary or unnecessary?
I don't know I was asking what your asking. I know back in my Cobra Days supposedly there was an issue with coolant flow at the back of the head. But you would have to imagine Ford has addressed it at this point right?


Leonidas514

Well-Known Member
Joined
Feb 25, 2021
Messages
212
Reaction score
63
Location
Oviedo, FL
First Name
Chad
Vehicle(s)
2015 GT
So many darn people run it. I've got a new kit sitting on my bench. Contemplating even installing it and my motors not in the car.


Inthehighdesert

Well-Known Member
Joined
Apr 9, 2017
Messages
1,411
Reaction score
1,191
Location
Albuq.
First Name
Charlie
Vehicle(s)
2016 gt convertible, 2020 GT350, 2020 GT350R
I can’t imagine how big of a pain in the arse it is from the engine side. I pulled the tranny to do it my 350. I had to change some routing on the drivers side and theres no way I would have been able to do it without the tranny out. I had to mess with the orientation on the passenger side as well. The kit does stop the hot spots on the back of the heads.


80FoxCoupe

Well-Known Member
Joined
Mar 28, 2018
Messages
3,142
Reaction score
2,621
Location
Cincy, OH
Vehicle(s)
16 GT, 80 Fox
I can’t imagine how big of a pain in the arse it is from the engine side. I pulled the tranny to do it my 350. I had to change some routing on the drivers side and theres no way I would have been able to do it without the tranny out. I had to mess with the orientation on the passenger side as well. The kit does stop the hot spots on the back of the heads.
What data is available that supports "stop the hot spots"?
